CONTROLS 27
5.13Indicator lamp overview
601033-10
Possible states
Reverse gear indicator lamp – No function.
Turn signal indicator light flashes green with the flashing rhythm – The
turn signal is switched on.
High beam indicator lamp lights up blue – The high beam is switched
on.
Idling speed indicator lamp lights up green – The transmission is
switched to idle.
5.14Emergency OFF switch with rip cord
601084-10
The emergency OFF switch is mounted on the left in front of the fuel tank.
The emergency OFF switch shuts the engine off if the rider falls off the vehicle.
Clip is attached to a rip cord that can be attached to the clothing of the rider by means
of carabiner .
Possible states
• Clip is pulled off – The ignition circuit is interrupted, a running engine stops and a
non-running engine will not start.
• Clip is mounted – The ignition circuit is closed and the engine can be started.
