TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 194

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw on fuel tank M6 6 Nm (4.4 lbf ft) –

Screw, clamping nut, rear axle M6 10 Nm (7.4 lbf ft) –

Screw, foot brake cylinder M6 7 Nm (5.2 lbf ft)

Loctite

243™

Screw, rear brake caliper M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shock absorber adjusting ring M6 5 Nm (3.7 lbf ft) –

Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bearing support, steering M8 25 Nm (18.4 lbf ft) –

Screw, front brake caliper M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, front brake disc M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, rear brake caliper M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, rear brake disc M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, rear wheel eccentric element M8 20 Nm (14.8 lbf ft) –

Screw, steering bridge M8 20 Nm (14.8 lbf ft) –

Screw, subframe M8 35 Nm (25.8 lbf ft)

Loctite

243™

Engine bracket screw M10 60 Nm (44.3 lbf ft) –

Engine mounting bolt M10 60 Nm (44.3 lbf ft) –

Nut, handlebar support M10 45 Nm (33.2 lbf ft) –

Remaining nuts, chassis M10 50 Nm (36.9 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, A-arm bottom M10x70 45 Nm (33.2 lbf ft) –
