6-24 Maintenance
Windows will automatically reboot itself.
(14) If XStreamDSO has started up, choose "Utilities Setup ..." from the "Utilities"
menu.
(15) Open the "Status" tab and check to make sure that the "Firmware Version" is
identical to the “3.6.0.11”(build 61005).
(16) Open the "Remote" tab and check to make sure that the main unit serial number
has been set as the "Host Name".
6.4.2.7 Validating the software
1. Turn on the power to the WaveSurfer.
(A) After the power is turned on, music shall be played when the OS
(Windows XP) starts up.
(B) "WaveSurfer" shall be displayed on the screen. If "WaveMaster"
appears, the system may fail to recognize the hardware.
(C) Make each channel active by pressing the corresponding channel
button (1, 2, ...). Then press the AUTO button and check to make sure
that each waveform is displayed correctly.
2. Adjusting the touch screen
(A) Click "Utilities Setup..." in "Utilities" on the top menu bar.
(B) From the "Utilities" menu, click "Touch-Screen Calibration".
(C) Correctly click the four X marks on the screen with a thin stick or the
like.
(D) Check to make sure that the cursor moves to the actually clicked point.
Important! Use caution not to damage the touch screen.
6.4.2.8 Initialization of panel setup
(1) Click "Recall Setup." of a top menu bar "File".
(2) Click "Recall Default Setup" of "Recall Setup" menu.
