LeCroy WaveSurfer 400 Series User Manual

6.7 Equipment and Spare Parts Recommended for Service
6.7.1 Test Equipment Required
See Table 5-1 in section 5.2.
6.7.2 WaveSurfer Spare Parts
LeCroy P/N Assembly Adjustments Performance
Tests
IW211857900 WS4-Processor RB80526RY None None
IW211857902 WS4-LCD CIRCUIT None None
IW211857903 WS454 PANEL BOARD None None
IW211857904 WS4X4 KEY BOARD None None
IW211857905 WS4X2 KEY BOARD None None
IW211857918 WS454 FE/ACQ BOARD None Chapter 5
IW211857921 WS452 FE/ACQ BOARD None Chapter 5
IW211857923 WS422 FE/ACQ BOARD None Chapter 5
IW211857920 WS424 FE/ACQ BOARD None Chapter 5
IW211857922 WS432 FE/ACQ BOARD None Chapter 5
IW211857919 WS434 FE/ACQ BOARD None Chapter 5
IW211857914 WS454 MAIN POWER UNIT None None
IW211857915 WS454 PFC CIRCUIT None None
IW211857916 WS454 INLET CIRCUIT None None
IWDZB100221 Hard disk MHT2030AT HDD Update None
IW211857901 WS PCI BRIDGE Add Keycodes Verify Model
IWKAS159811 WS4 TFT TOUCHSCREEN ASSY Touchscreen None
See chapter 7 for mechanical replaceable parts.
Maintenance 6-29
