7.4 OUTER Replaceable Parts
Item
Fig. No
Part Number Quantity Description *Location
1
IW
MKB130069 15 SCREW KB (+) 3X6S A1-6, B1-7,C1-2
2
IW
KCM148511 4 WS FOOT BASE UL-I C1-4
3
IW
KGM030211 2 WS RUBBER FOOT UL-I A2-2
4
IW
MKB130089 4 SCREW KB (+) 3X8S C1-4
5
IW
MSQ920911 4 NYLON WASHER (2.8X7.5X0.5) B1-2, C1-2
6
IW
KCM148421 2 WS ANGLE FOOT UL-I C1-2
7
IW
MKD140101 2 SCREW KD (+) 4X10S B1-2
8
IW
KPL143911 1 FSN CUSHION B B2
9
IW
KPL145511 1 WS I-O CUSHION 153 UL-I B2
10
IW
KPL145611 2 WS I-O CUSHION 40 UL-I B2-2
11
IW
KBA806121 1 WS UNDER COVER C1
12
IW
KBA806221 1 WS TOP COVER B1
13
IW
MTH000791 1 HANDLE THA-238-L260 UL-I B1
14
IW
KRA227411 1 LABEL 12.5X50 B1
15
IW
KRA250611 1 ETHERNET POST STICKER B1
16
IW
KRA226821 1 SERIAL NUMBER LABEL A1
*Location
(ex) A1-6: It is shown to use 6 pieces in figure [A1].
7.5 REAR & SIDE Replaceable Parts
Item
Fig. No
Part Number Quantity Description Location
17 IWKGM029111 4 FSN RUBBER FOOT A1-4
18 IWKCM149111 4 WS CORD HOOK UL-I A1-4
19 IWKRA249511 2 WS HOLE LABEL UL-I A1-2
20 IWKRA248111 1 WS WARNING LABEL UL-I A1
21 IWKRA249211 1 WS BATTERY LABEL UL-I A1
22 IWKCM148911 1 WS REAR PANEL UL-I A1
23 IWKPA224411 1 WS I-O OVER LAY B1
24 IWKRA248211 1 WS PATENT LABEL UL-1 A1
25 IWKRA247911 1 WINDOWS XP-E LICENSE G/
LICENSE SEAL
A1
26 IWMSQ901661 4 SCREW TT2 (+)3X8S
A2-4
Mechanical Part & Removal 7-5
