5-2 Performance Verification Rev. D Sept 2007
5.2 Test Equipment Required
These procedures use external, traceable signal generators, DC precision power
supply and digital multi-meter, to directly check specifications.
Instrument Specifications Recommended
Signal Generator
Radio Frequency
Frequency : .5 MHz to 1 GHz
Frequency Accuracy : 1 PPM
HP 8648B or C or
Fluke 9500
Signal Generator
Audio Frequency
Frequency : 0 to 5 kHz
Amplitude : 8 V peak to peak
HP 33120A
Voltage Generator
DC Power Supply
Range of 0 to 20 V, in
steps of no more than 15 mV
HP 6633A
Power Meter +
Sensor
Accuracy ±1 %
HP437B + 8482A or
equivalent
Digital Multimeter
Volt & Ohm
Voltmeter Accuracy : 0.1 %
Ohmmeter Accuracy : 0.1 %
Keithley 2000, Fluke 9500
or 5820 Oscilloscope
Calibrator
Coaxial Cable, 5 ns
50Ω, BNC, length 100 cm,
Coaxial Cable, 5 ns
50Ω, SMA, length 100 cm,
2 Attenuators, 20 dB
50Ω, BNC, 1 % accuracy
T adapter
50Ω, BNC T adapter
Table 5-1 : Test Equipment
5.2.1 Test Records
The last pages of this chapter contain the WaveSurfer 400 series test records in the
format of tables. Keep them as masters and use a photocopy for each calibration.
5.3 Turn On
If you are not familiar with operating the WaveSurfer 400, refer to the operator's
manual.
Switch on the power using the power switch.
Wait for about 20 minutes for the scope to reach a stable operating
temperature:
To provide for quicker setup of the scope for each test, a CD containing panel
setups has been included with this manual. An external USB CD ROM drive will
need to be connected if you wish to use these. Detailed set up information is
contained in the text and the panel setups are not needed if a CD ROM drive is
not available.
