LeCroy WaveSurfer 400 Series User Manual

7.8 FRAME Replaceable Parts (MAIN BOARD, POWER BOARD, CPU BOARD)
Item
Fig. No
Part Number Quantity Description
Location
1 IWMKB130062 13 SCREW KB (+) 3X6S(NIP) G1, G2-2
2 IWMKP130301 8 SCREW KP (+) 3X30S J1
3 IWMSM430061 4 SM4-3X6 F1
4 IWAGM000111 4 Rubber Feet 16Ø F1
5 IWMSM440081 3 SM4-4X8 J1
6 IWKBA805421 1 WS HDD PLATE F1
7 IWKBA805511 1 WS MAIN CHASSIS I2
8 IWKBA805621 1 WS CPU FRAME J1, G1
9 IWKPA224411 1 WS I-O OVER LAY UL-I G1
10 IWKBA807411 1 WS I-O SHEILD PLATE J1
11 IWKAS094511 1 GRAND TERMINAL B I2
12 IWDCN040801 1 BNC RECEPTACLE I2
13 IWMZT006121 - FINGER TWIST 97-555 G3
7.9 Spare Parts
Part Number Description
IW211857900 WS4-Processor RB80526RY
IW211857902 WS4-LCD CIRCUIT
IW211857903 WS454 PANEL BOARD
IW211857904 WS4X4 KEY BOARD
IW211857905 WS4X2 KEY BOARD
IW211857918 WS454 MAIN UNIT
IW211857921 WS452 MAIN UNIT
IW211857923 WS422 MAIN UNIT
IW211857920 WS424 MAIN UNIT
IW211857922 WS432 MAIN UNIT
IW211857919 WS434 MAIN UNIT
IW211857914 WS454 MAIN POWER UNIT
IW211857915 WS454 PFC CIRCUIT
IW211857916 WS454 INLET CIRCUIT
IWDZB100221 Hard disk MHT2030AT
IW211857902 WS4-LCD CIRCUIT
Mechanical Part & Removal 7-15
