Leica mojo3D, Automatic Section Control 157
7.4 Section Override Control
Section override
control, step-by-
step
To override the automatic section control, carry out the following steps:
1. With the master on and coverage being recorded, tap anywhere on the horizontal
section control bar at the bottom of the screen.
2. Tap a section on the section
control override bar, or tap or
to select a section to override.
3. Tap Auto, On or Off to set the override state.
• On: The section will apply coverage when the master record button is on
(blue), even when travelling over an area already covered.
• Off: The section is turned off, and will not apply coverage.
• Auto: Auto section control will operate as normal.
4. Or, change all the settings at once by tapping All Auto, All On, or All Off.
5. Tap to close the section override control.
