74
Leica mojo3D, Setting Guidance Types
4.4 Pivot Guidance
General informa-
tion
Setting pivot guid-
ance, step-by-step
To set up pivot guidance, carry out the following steps:
In pivot guidance, working lines are concentric
circles and are defined by setting three waypoints.
Before you can set waypoints, the
system must have a good position fix.
1. On the main navigation screen, tap the guidance button.
2. On the flyout menu, tap the pivot guidance button.
3. Position your vehicle in the field at the position where you want to
start (waypoint A), and tap the A point button.
4. Drive to waypoint B, and tap the B point button.
