Leica mojo3D, Running the mojo3D for the First Time 55
3.8 View Modes
View modes There are four different view modes available:
• First person: zoomed-in as far as possible.
• Chase: behind the triangle or three-dimensional vehicle icon.
• Top down (north up): a view from above the vehicle where map is shown with
north always at the top of the screen.
• Top down (heads up): a view from above the vehicle with map shown from the
drivers point of view forwards.
The mojo3D remembers the current view mode when it is shutdown, so when it is
restarted the same view mode displays.
Changing the view
mode, step-by-
step
To change the view mode between First person, Chase and Top down, carry out the
following steps:
1. Touch the middle of the screen, to display the zoom buttons.
2. Tap either or repeatedly, until the view mode changes.
To change between Top Down North Up and Top Down Heads Up refer to "3.11
Changing System Settings".
