248

Leica mojo3D, Safety Directions

14 Safety Directions

14.1 General Introduction

Description • The following directions should enable the person responsible for the product,

and the person who actually uses the equipment, to anticipate and avoid opera-

tional hazards.

• The person responsible for the product must ensure that all users understand

these directions and adhere to them.
