Configuration
Code table
8
8.3
8.3-23
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0351 CAN baud rate 0
0 500 kbits/s
Baud rate of system bus
z Change is effective after
command ”Reset-Node”
1 250 kbits/s
2 125 kbits/s
3 50 kbits/s
4 1000 kbits/s
C0352 CAN mst 0
0 Slave
Configuration of system bus
devices
z Change is effective after
command ”Reset-Node”
1 Master
C0353
0 C0350 is the source
Source of the system bus address
1 C0354 is the source
1 CAN ADDR SEL1 0 CAN IN1/OUT1
2 CAN ADDR SEL2 0 CAN IN2/OUT2
3 CAN addr sel3 0 CAN IN3/OUT3
C0354 1 {1} 512 Selective system bus address
z Individual addressing of the
system bus process data
objects
1 IN1 addr 2 129 CAN-IN1
2 OUT1 addr 2 1 CAN-OUT2
3 IN2 addr 2 257 CAN-IN2
4 OUT2 addr 2 258 CAN-OUT2
5 IN3 addr 2 385 CAN-IN3
6 OUT3 addr 2 386 CAN-OUT2
C0355 0 {1} 2047
System bus identifier
z Display only
1 CAN-IN1 Id
2 CAN-OUT1 Id
3 CAN-IN2 Id
4 CAN-OUT2 Id
5 CAN-IN3 Id
6 CAN-OUT3 Id
C0356 0 {1 ms} 65000 System bus time setting
1 CAN BOOT UP 3000 Essential for CAN system without
master
2 OUT2 cycle 0
0 = event-controlled process data
transfer
>0=cyclicprocessdatatransfer
3 OUT3 cycle 0
4 CAN DELAY 20 Waiting time to the start of cyclic
sending after boot-up
C0357 0 {1 ms} 65000 System bus monitoring times
z The CAN objects remain in
receive position after a fault
message
1 CE1MONIT TIME 3000 CAN-IN1
2 CE2monit time 3000 CAN-IN2
3 CE3monit time 3000 CAN-IN3
C0358 Reset node 0
0 no function
Installing system bus reset nodal
point
1 CAN reset
C0359 CAN state
0 Operational
System bus status
z Display only
1 Pre-Operational
2 Warning
3 Bus off
