Configuration
Code table
8
8.3

8.3-46
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0741 STATUS 0 1000000000
Function block OSZ
z Read only
See System
Manual
(extension)
1 Version
2 Memory size
3 Data width
4 Number of
channels
C0742 Data block
length
8 0 {1} 65536 Function block OSZ
C0743 Read data block
length
(OSZ)
0 65535 Function block OSZ
z Read only
z Reading an 8 byte data block
C0744 Memory depth 3
0 512 measured values
Oscilloscope function
z Adapt memory capacity to the
measurement task
1 1024 measured values
2 1536 measured values
3 2048 measured values
4 3072 measured values
5 4096 measured values
6 8192 measured values
C0749 0 65535 Information about storing the
measured values, function block
OSZ
z Read only
See System
Manual
(extension)
1 Abort index Measured value no. of the abort
time
2 Trigger index Measured value no. of the trigger
time
3 End index Measured value no. of the end
time
C0750 Vp denom 16
1 1
Gain V
P
of the position controller,
function block DFRFG1
 8.2-13
2 1/2
4 1/4
8 1/8
16 1/16
32 1/32
64 1/64
128 1/128
256 1/256
512 1/512
1024 1/1024
2048 1/2048
4096 1/4096
8192 1/8192
16384 1/16384
