Configuration
Code table
8
8.3
8.3-48
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0775
CFG: D 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block FLIP2
See System
Manual
(extension)
C0776
CFG: CLK 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block FLIP2
z Each LOW-HIGH edge at
FLIP2-CLK switches the signal
at FLIP2-D to FLIP2-OUT
C0777
CFG: CLR 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block FLIP2
z Resets the flip-flop
z HIGH: sets FLIP2-OUT = LOW
z Inputhashighestpriority
C0778 0 1
Function block FLIP2
z Display of the signals linked in
C0775, C0776 and C0777
1 DIS: D
2 DIS: CLK
3 DIS: CLR
C0780
CFG: N 5250 NLIM1-OUT Selection list 1 Configuration of analog input
signal, function block NSET
z Main setpoint
See System
Manual
(extension)
C0781
CFG: N-INV 10251 R/L/Q-R/L Selection list 2 Configuration of digital input
signal, function block NSET
z HIGH: main setpoint (C0780) is
inverted
C0782
CFG: NADD 55 AIN2-OUT Selection list 1 Configuration of analog input
signal, function block NSET
z Additional setpoint
C0783
CFG: NADD-INV 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block NSET
z HIGH: additional setpoint
(C0783) is inverted
C0784
CFG: CINH-VAL 5001 MCTRL-NACT Selection list 1 Configuration of analog input
signal, function block NSET
z The signal is accepted by the
main setpoint integrator when
the controller is inhibited
C0785
CFG: SET 5000 MCTRL-nset2 Selection list 1 Configuration of analog input
signal, function block NSET
z When NSET-LOAD = HIGH, the
signal is accepted by the main
setpoint integrator
C0786
CFG: LOAD 5001 MCTRL-QSP-OUT Selection list 2 Configuration of digital input
signal, function block NSET
z HIGH: The signal at NSET-SET
is accepted by the mains
setpoint integrator
z Control of both ramp function
generators in special
situations,e.g.quickstop
