 HDMI-TPS-RX110AY – User's Manual 57

INFO: Serial (local and link) port numbering can be found in the  section.
Protocol Setting
Command format: SET●
n

Response format: pw●
n

Parameters:
.ControlProtocol 0 1
RS-232 protocol mode  
Example:
˃ SET /MEDIA/UART/P1.ControlProtocol=1
˂ pw /MEDIA/UART/P1.ControlProtocol=1
BAUD Rate Setting
Command format: SET●
n

Response format: pw●
n

Parameters:
.Baudrate 0 1 2 3 4 5 6 7
BAUD rate value 4800 7200 9600 14400 19200 38400 57600 115200
Example:
˃ SET /MEDIA/UART/P1.Baudrate=2
˂ pw /MEDIA/UART/P1.Baudrate=2
Databit Setting
Command format: SET●
n

Response format: pw●
n

Example:
˃ SET /MEDIA/UART/P1.DataBits=8
˂ pw /MEDIA/UART/P1.DataBits=8
Stopbits Setting
Command format: SET●
n

Response format: pw●
n

Parameters:
.StopBits 0 1 2
Stopbit value 1 1,5 2
Example:
˃ SET /MEDIA/UART/P1.StopBits=0
˂ pw /MEDIA/UART/P1.StopBits=0
Parity Setting
Command format: SET●
n

Response format: pw●
n

Parameters:
.Parity 0 1 2
Parity setting no parity odd even
Example:
˃ SET /MEDIA/UART/P1.Parity=0
˂ pw /MEDIA/UART/P1.Parity=0
RS-232 Operation Mode
Command format: SET●
n

Response format: pw●
n

Parameters:
.Rs232Mode 0 1 2
RS-232 operation mode Pass-through Control Command injection
Example:
˃ SET /MEDIA/UART/P1.Rs232Mode=1
˂ pw /MEDIA/UART/P1.Rs232Mode=1




