HDMI-TPS-RX110AY – User's Manual 60
Command format: SET●
n
Response format: pw●
n
Example:
˃ SET /MEDIA/IR/D2.EnableModulation=false
˂ pw /MEDIA/IR/D2.EnableModulation=false
Explanation:
Signal modulation is turned off on TPS IR output line (D2).
INFO: The default setting value is "true" (enabled).
Relay Port Settings
Set Relay Connection State
Command format: SET●
n
Response format: pw●
n
Parameters:
.Output O C
Relay connection state Open Closed
Example:
˃ SET /MEDIA/RELAY/P1.Output=C
˂ pw /MEDIA/RELAY/P1.Output=C
Explanation: P1 relay port is set to be closed.
EDID Management
Command format: GET●
Response format: pr●
1
2
n
Example:
˃ GET /EDID.EdidStatus
˂ pr /EDID.EdidStatus=D1:E1
Explanation:
Emulated EDID memory for input port is listed with the EDID number that is currently emulated on the input.
Command format: GET●
n
Response format: pr●
n
Example:
˃ GET /EDID/D/D1.Validity
˂ pr /EDID/D/D1.Validity=true
Explanation:
Command format: GET●
n
.PreferredResolution
Response format: pr●
n
Example:
˃ GET /EDID/U/U2.PreferredResolution
˂ pr /EDID/U/U2.PreferredResolution=1920x1080p60.00Hz
INFO: Use the "Manufacturer" property to query the manufacturer and the "MonitorName" property to
query the name of the monitor.
Emulating an EDID to an Input Port
Command format ●
Response format: mO●
Example:
˃ CALL /EDID:switch(F49:E2)
˂ mO /EDID:switch
Legend:
The emulated EDID memory of the desired input port.
