Maintenance work on the carrier
7.7 Transfer case
16.11.2018
Maintenance manual 3 302 756 en 7 - 55
GMK6400
Changing the oil
• Place a receptacle underneath the
screws
(2).
• Unscrew bolts (1) and (2) and allow the oil to
drain.
• Replace the seal and tighten the screws (2).
• Fill the oil up to the lower edge of the
opening.
• Replace the seal and tighten the screws (1).
Inspections after
an oil change
• Go for a test drive.
• Switch the engine off and wait about
5 minutes.
• Check the oil level; à p. 7 - 53.
• Check drain plugs (1) and (2) for leaks.
G
Risk of scalding from gear oil at operating temperature!
You could scald yourself by gear oil escaping in an uncontrolled manner at
operating temperature. Wear appropriate protective gloves and take care
not to come into contact with the gear oil.
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
