Maintenance work on the carrier
7.10 Vehicle brake
16.11.2018
Maintenance manual 3 302 756 en 7 - 77
GMK6400
7.10 Vehicle brake
7.10.1 Checking the brake lining thickness
Spare parts
and
tools
– Measuring tool for brake linings.
Prerequisites – The truck crane must be parked over an inspection pit.
– The truck crane must be raised on outriggers.
– The engine must not be running and must be secured against unauthor-
ised use; à p. 2 - 3.
– The parking brake must be released.
Safety
instructions
• Do not perform repair work on the vehicle brakes;
à Maintenance instructions, p. 1 - 2.
• Perform only maintenance work; à Checking, p. 7 - 78.
s
M 3
Designation Quantity
per axle
line
GROVE part no.
1st and 2nd Axle lines (duplex brake)
Brake shoe with brake lining 4 03322112
Spring 4 03322110
Brake drum 2 01925703
3rd to 6th axle line (simplex brake)
Brake shoe with brake lining 4 03322121
Spring 4 02315393
Brake drum 2 01925703
G
Risk of accidents due to incorrect work on the vehicle brakes!
Incorrect work on the vehicle brakes can lead to failure of the brakes
causing severe accidents.
Incorrect work invalidates the operating approval of the truck crane and no
claims of liability for damage can then be accepted.
All repair work on the vehicle brakes may only be performed by
Manitowoc Crane Care or an authorised GROVE dealer or an authorised
specialist workshop with specially trained repair crew.
