Manitowoc GROVE GMK6400 User Manual

Lubricants and consumables
6.1 Lubricants
16.11.2018
Maintenance manual 3 302 756 en 6 - 3
GMK6400
6.1.2 Lubricant applications list
Con-
sec.
No.
Lubricant
type
Usage Fill
quantity
in litres
(gal)
Mainte-
nance
interval
1 Engine oil Carrier diesel engine; à p. 7 - 24 27 (7.1) Y 2
2 Gear oil
Transmission without Intarder;
à p. 7 - 45 15 (4.0) Y 3
Transmission with Intarder; à p. 7 - 45 25 (6.6) Y 3
Power take-off; à p. 7 - 49 4.5 (1.2) Y 3
3 Gear oil
Transfer case;
à p. 7 - 54 8 (2.1) M 6
1. Axle centre drive axle line; à p. 7 - 61 14.0 (3.7) M 12
2. Axle centre drive axle line; à p. 7 - 61 15.0 (4.0) M 12
1. + 2nd axle line:
4x final drives;
à p. 7 - 64
3.8 (1.0) M 12
4th + 5th axle line:
4x final drives;
à p. 7 - 64
6.0 (1.6) M 12
4 Gear oil 12x suspension struts; à p. 7 - 79 1.5 (0.4) M 1
5 Gear oil Pump transfer case; à p. 8 - 37 4.6 (1.2) M 12
6 Gear oil
Main hoist;
à p. 8 - 14 7 (1.9) M 12
Auxiliary hoist; à p. 8 - 14 11.5 (3.0) M 12
3x slewing gears; à p. 8 - 20 0.9 (0.24) M 12
7 Hydraulic oil
Carrier hydraulic tank;
à p. 7 - 99 230 (61) M 12
Superstructure hydraulic tank; à p. 8 - 57 1,320 (349) M 12
s
