Maintenance work on the carrier
7.3 Engine
7 - 24 3 302 756 en Maintenance manual
GMK6400
16.11.2018
7.3.8 Changing the oil and oil filter
Oil, spare parts,
tools
– Receptacle, about 30 l (8 gal); à p. 2 - 4.
– Torque wrench for a torque of 40 Nm (29.5 lbf ft).
– Socket wrench SW 36.
– Connecting piece and hose (toolbox); à p. 7 - 100.
Prerequisites • Find out the prescribed oil specification and the necessity of shortening
the maintenance interval under special operating conditions;
à Engine manufacturer's documentation.
• Find out about the safety instructions and the sequence of steps for
changing the oil and oil filter;
à Engine manufacturer's documentation.
– The truck crane must be level.
– The engine must not be running and must be secured against unauthor-
ised use; à p. 2 - 3.
Changing
If a valve is already mounted on the oil pan:
Y 2
Engine oil
in litres (gal)
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
27 (7.1) HD - CD MIL-L 2104 C
DB 228.5
SAE 5 W-30
03329588
Designation Quantity GROVE part no.
Oil filter with gasket 1 03328365
Gasket for oil drain plug
for diesel engine with AdBlue system
1 03329824
Gasket for oil drain plug
for diesel engine without AdBlue system
1 03329825
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
O
Risk of environmental damage due to leaking consumables!
If a valve is mounted on the oil pan, use the delivered connecting piece with
hose and a receptacle with adequate capacity to drain the oil.
