Spare parts required for maintenance
11.3 Spare parts for the carrier
16.11.2018
Maintenance manual 3 302 756 en 11 - 5
GMK6400
11.3 Spare parts for the carrier
Assemblies and spare parts
carrier
GROVE
Part number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Engine
Valve M 20 x 1.5
Gasket 20 x 24 Cu DIN 7603
03041579
Once when the oil is changed the first
time;
recommended modification from
oil drain plug to valve
00117139
Valve M 26 x 1.5
Gasket 26 x 31 Cu DIN 7603
03046878
00117147
Air filter 03328262 1 item when the symbol lights up
Fuel system
Filter (filter 1)
Gasket
Filter element (if damaged)
03322877 1
03322879 1
03328656 1
Filter with gasket (Filter 2) 03319653 1
Transmission
O-ring 21 x 2
04155708 On the transmission 1
Gasket 26 x 31 Cu DIN 7603 00117147 On the power take-off 1
Transfer case
Gasket 30 x 36 Cu DIN 7603
00117151 1 1
Gasket 16 x 20 Cu DIN 7603 00117134 1
Axle lines Axle centre drives
Gasket 30 x 36 Cu DIN 7603
00117151 2 2
Gasket 24 x 29 Cu DIN 7603 00117145 2
Gasket 36 x 42 Cu DIN 7603 01371208 2
Axle lines Final drives
Gasket 24 x 29 Cu DIN 7603
00117145 8 8
Gasket 30 x 36 Cu DIN 7603 00117151 4
Wheels
Wheel nuts for steel rims
01207756
In case of damage;
12 each per wheel
Wheel nuts for aluminium rims 7659100000
s
