Maintenance work on the carrier
7.8 Axle lines
16.11.2018
Maintenance manual 3 302 756 en 7 - 65
GMK6400
Draining oil
On the axle line 1, 2, 4 and 5
• Turn the wheel until the bolt (1) is at the
bottom.
• Use a drain channel and place a receptacle
under the screw.
• Remove the screw and let the oil drain out.
Additionally on the axle line 4 and 5
• Place a receptacle underneath the screw (1).
• Remove the screw and let the oil drain out.
• Fit a new gasket and tighten the screw.
