Mindray A7 Operating Instructions

Waveform/Spirometry Tabs Parameters and Factory Defaults
C - 2 046-004667-00 A7™ Operating Instructions
C.1 Waveform/Spirometry Tabs
C.2 Alarm Limits
OBJECT RANGE DEFAULT
Waveform/Spirometry Tab Waveform tab, Spirometry tab Waveform tab
Spirometry Tab: Loop Type Pressure - Volume, Flow - Volume,
Pressure- Flow
Pressure - Volume
Spirometry Tab: Save Loop Reference, Baseline Reference
Spirometry Tab: Show
Reference
Off, Baseline, [time] Off
Spirometry Tab: Review Loops:
Loop Type
Pressure - Volume, Flow - Volume,
Pressure- Flow
Pressure - Volume
PARAMETER RANGE DEFAULT UNIT
PEAK High The greater of 10 and (PEAK
Low+1) to 100
Step: 1
Adult: 50
Pediatric: 40
Infant: 40
cmH
2
O
PEAK Low 0 to the lesser of 70 and (PEAK
High–1)
Step: 1
Adult: 10
Pediatric: 8
Infant: 4
cmH
2
O
MV High The greater of 0.2 and (MV
Low+0.1) to 25
Step: 0.1
Adult: 12
Pediatric: 6
Infant: 6
L/min
MV Low 0 to the lesser of 20 and (MV
High–1)
Step: 0.1
Adult: 1
Pediatric: 1
Infant: 0.2
L/min
FiO
2
High The greater of 21 and (FiO
2
Low+1) to 100, Off
Step: 1
Off %
FiO
2
Low 18 to the lesser of 98 and (FiO
2
High–1)
Step: 1
18 %
EtCO
2
High Off, 2 to 99
Step: 1
Adult: 50 mmHg
Pediatric: 50 mmHg
Infant: 45 mmHg
mmHg, % kPa
EtCO
2
Low Off, 0 to 97
Step: 1
Adult: 25 mmHg
Pediatric: 25 mmHg
Infant: 30 mmHg
mmHg, % kPa
FiCO
2
High Off, 1 to 99
Step: 1
4%
EtN
2
O High Off, (Low+2) to 100
Step: 1
55 %
EtN
2
O Low Off, 0 to (High-2)
Step: 1
0%
FiN
2
O High Off, (Low+2) to 100
Step: 1
53 %
