Field Replaceable Unit 8-1
8 Field Replaceable Unit
This chapter lists the details of the Field Replaceable Units (FRU) of the system. Please refer to the explosive view and the FRU table below.
Level 0 represents the main assemblies of the system, and the whole system is divided into 7 assemblies.
Level X represents the main parts of Level 0 assembly.
Level X-1 represents the sub-parts of Level X.
If order number is provided in the table, it means that the part is an FRU and can be ordered; if the order number is not provided in the table, it means
that the part is not an FRU and cannot be ordered.
