12-10 Care and Maintenance

12.3.4 Mechanical Safety Inspection

Mechanical safety inspection is mainly used to check mechanical strength and mechanical function

of the key assembly of ultrasonic system. The mode of test evaluation mainly is: Perform the

evaluation by means of visual check and operating check, if the check result cannot pass, the

system is in abnormal status now. Stop using the system and adopt proper measures. The test flow

is as following:

Check the handle

Check control panel And

supports

Check the turning and

moving of monitor

Check other mechanics

Check the connection of the

casters

Check the casters

Check the turning and lifting

Fig 12-4 Mechanical Safety Inspection Flow
