B-16
PR
Measurement range 20 to 254 1/min
Resolution 1 1/min
Accuracy ±3 1/min
Data update period ≤30 s
PI
measurement range 0.05 %~20 %
Resolution 0.05 ～ 9.99 %: 0.01 %
10.0 ～ 20.0 %: 0.1 %
SpO
2
alarm limits Range Step
SpO
2
high limit 2 to 100 %
1 %
SpO
2
low limit 0 to 98 %
Desat limit 0 to 98 %
PR alarm limit Range Step
PR high limit 17 to 300 1/min
1 1/min
PR low limit 15 to 298 1/min
B.12 O
2
Sensor Specifications
O
2
sensor
Output 9 to 13 mV at 210 hPa O
2
Range 0 to 1500 hPa O
2
100% O
2
signal deviation 100 ± 1 %
Resolution 1 hPa O
2
Expected service life 1.5 x 106 % for measurement (20 °C)
0.8 x 106 % for measurement (40 °C)
Response time (21 % air to 100 % O
2
) <15 s
Linearity Linear 0-100 % O
2
Operating temperature range -20 °C to +50 °C
Temperature compensation ±2 % of fluctuation at 0 to 40 °C
Pressure range 50 to 200 kPa
Relative humidity 0 to 99%
100% O
2
concentration output drift Over one year of typical value <5%
Material White ABS
Packaging Sealed package
Period of validity Not more than 13 months after unpacked (in compliance
with the conditions specified by the manufacturer)
