3-1
3 Installations and Connections
WARNING
Do not use antistatic or conductive masks or patient tubing. They can cause burns
if they are used near high frequency electrosurgery equipment.
To ensure optimum performance of the ventilator, re-do System Check each time
after changing the patient type, replacing the accessories or components like
patient tubing, humidifier, and filter.
Adding accessories or other components to the breathing system of the ventilator
can increase system inspiratory and expiratory resistance.
3.1 Install the Main Unit
A. Main unit B. Positioning post C. Trolley unlocking button D. Trolley
Align the main unit with the two positioning posts on the trolley and put it onto the trolley in
place.
To remove the main unit from the trolley, depress the trolley unlocking button and then lift it
up with both hands.
A
B
C
D
