2.2.2 Rear View
1. Cylinder retaining clip
For retaining the gas cylinder.
2. Trolley rear handle
3. DC power connector
4. AC power receptacle
5. VGA connector
Outputs VGA video signals with the same contents to the primary display and connects
to the external display (supporting display with resolution of 1280*800).
6. USB connector
Conducts ventilator software upgrade, configuration information and history data (such
as patient data, alarm log, calibration table) export, configuration transfer between
machines of the same type via USB device.
