8-18
Chapter 8 FUEL SYSTEM
1.6 Fuel Injection Pump - Remove and Inspect
Fuel Injection Pump - Remove and Inspect
2
4
3
5
1
1
MTK2, MTK3 spec
Removing Sequence
1 Coupling cover
2 Bracket
3 Bracket
4 Fuel injection pump (Approx 56 kg [123 lb])
5 Bracket
