Chapter 11 INLET AND EXHAUST SYSTEMS
Chapter 11 INLET AND EXHAUST SYSTEMS
1. Inlet and Exhaust Systems - Remove and Inspect
1.1 Inlet Ststem - Remove and Inspect
Inlet System - Remove and Inspect
Fresh water air cooler spec
1
2
3
Replace
Replace
Replace
Removing Sequence
1 Connector
2 Duct
3 Air cooler (Fresh water air cooler internal cooling
water cool exhaust manifold spec: approx 51 kg [112 lb])
(Fresh water air cooler external cooling
water cool exhaust manifold spec: approx 55 kg [121 lb])
