9-6
Chapter 9 LUBRICATION SYSTEM
1.4 Governor Oil Filter - Remove and Inspect
Governor Oil Filter - Remove and Inspect
A
1
2
3
4
3
4
5
Governor
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Timing gear case
Timing gear case
To crankcase
To crankcase
A
A
B
EG3P governor spec
B
Oil pressure governor spec
*Woodward EG-3P governor
Removing Sequence
1 Oil pipe
2 Oil pipe
3 Oil pipe
4 Oil pipe
5 Governor oil filter
