9-11
Chapter 9 LUBRICATION SYSTEM
2.4 Relief Valve - Disassemble and Inspect
Relief Valve - Disassemble and Inspect
Left oil filter spec
Right oil filter spec
4
5
2
3
1
Settling
Disassembling Sequence
1 Stopper
2 Spring
3 Relief valve
4 Sleeve
5 Plate
