Mitsubishi S6R2 Series User Manual

9-13
Chapter 9 LUBRICATION SYSTEM
2.7 Oil Cooler and Oil Thermostat - Disassemble
Oil Cooler and Oil Thermostat - Disassemble
1
5
6
2
7
4
3
Replace
Replace
Clogging, flaw, crack
Replace
Replace
Disassembling Sequence
1 Nut
2 Oil cooler cover
3 Packing
4 Element
5 Oil thermostat
6 Sealing
7 Plug
Replace packings and O-rings with new ones when assembling.
