Instruction Set Summary
3-6 MC68030 USER’S MANUAL MOTOROLA
3.2.3 Logical Instructions
The logical operation instructions (AND, OR, EOR, and NOT) perform logical operations
with all sizes of integer data operands. A similar set of immediate instructions (ANDI, ORI,
and EORI) provide these logical operations with all sizes of immediate data. The TST
instruction compares the operand with zero arithmetically, placing the result in the condition
code register. Table 3–3 summarizes the logical operations.
Table 3-2. Integer Arithmetic Operations
Instruction Operand Syntax Operand Size Operation
ADD
ADDA
Dn, 〈 ea 〉
〈 ea 〉 ,Dn
〈 ea 〉 ,An
8, 16, 32
8, 16, 32
16, 32
source + destination → destination
ADDI
ADDQ
# 〈 data 〉 , 〈 ea 〉 # 〈 data 〉 ,
〈 ea 〉
8, 16, 32
8, 16, 32
immediate data + destination → destination
ADDX Dn,Dn
–(An),–(An)
8, 16, 32
8, 16, 32
source + destination + X → destination
CLR 〈 ea 〉 8, 16, 32 0 → destination
CMP
CMPA
〈 ea 〉 ,Dn
〈 ea 〉 ,An
8, 16, 32
16, 32
destination - source
CMPI # 〈 data 〉 , 〈 ea 〉 8, 16, 32 destination - immediate data
CMPM (An) +,(An) + 8, 16, 32 destination - source
CMP2 〈 ea 〉 ,Rn 8, 16, 32 lower bound < = Rn < = upper bound
DIVS/DIVU
DIVSL/DIVUL
〈 ea〉,Dn
〈ea〉,Dr:Dq
〈ea〉,Dq
〈ea〉,Dr:Dq
32/16 → 16:16
64/32 → 32:32
32/32 → 32
32/32 → 32:32
destination/source → destination (signed or unsigned)
EXT
EXTB
Dn
Dn
Dn
8 → 16
16 → 32
8 → 32
sign-extended destination → destination
MULS/MULU 〈ea〉,Dn
〈ea〉,Dl
(ea〉,Dh:Dl
16x16 → 32
32x32 → 32
32x32 → 64
source y destination → destination (signed or unsigned)
NEG 〈ea〉 8, 16, 32 0 - destination → destination
NEGX 〈ea〉 8, 16, 32 0 - destination - X → destination
SUB
SUBA
〈ea〉,Dn
Dn,〈ea〉
〈ea〉,An
8, 16, 32
8, 16, 32
16, 32
destination = source → destination
SUBI
SUBQ
#〈data〉,〈ea〉
#〈data〉,〈ea〉
8, 16, 32
8, 16, 32
destination - immediate data → destination
SUBX Dn,Dn
–(An),–(An)
8, 16, 32
8, 16, 32
destination - source — X → destination
