NAiS FP Series User Manual

FPΣ
Functions and Restrictions of the Unit
1-6
1.2 Unit Types
This section explains the type of unit used with the FPΣ and about the optional
communication cassette.
1.2.1 FPΣ Control Unit
Name Number of I/O points Part No. Product No.
Input: 16 points/Transistor output: 16 points FPG-C32T AFPG2543
FPΣ Control unit
Input: 16 points/Transistor output: 16 points FPG-C32T2 AFPG2643
Input: 16 points/Relay output: 8 points FPG-C24R2 AFPG2423
1.2.2 FPΣ Expansion Unit
Name Number of I/O points Part No. Product No.
FPΣ expansion I/O unit Input: 32 points/Transistor output: 32 points FPG-XY64D2T AFPG3467
* The FPΣ expansion I/O unit can be used for “FPG-C32T2 and FPG-C24R2” FPΣ
control units.
1.2.3 Units for FP0 and FPΣ
The FPΣ can be used the FP0 series expansion I/O unit, power supply unit, and
intelligent unit.
1.2.4 Communication Cassette
A detachable communication cassette (optional) should be used when using the
various functions such as the computer link, serial data communication, and PLC link
functions.
Name Description Part No. Product No.
FPΣ Communication
cassette 1-channel
RS232C type
This communication cassette is a 1-channel unit with
a five-wire RS232C port. It supports 1 : 1 computer
links and general-purpose serial communication. RS/
CS control is possible.
FPG-COM1 AFPG801
FPΣ Communication
cassette 2-channel
RS232C type
This communication cassette is a 2-channel unit with
a three-wire RS232C port. It supports 1 : 1 computer
links and general-purpose serial communication.
Communication with two external devices is possible.
FPG-COM2 AFPG802
FPΣ Communication
cassette 1-channel
RS485 type
This communication cassette is a 1-channel unit with
a two-wire RS485 port. It supports 1 : N computer
links(C-NET),general-purposeserialcommunication,
and a PLC link.
FPG-COM3 AFPG803
