NAiS FP Series User Manual

FPΣ
Specifications
13 - 10
13.2 I/O No. Allocation
FP
Σ
Control unit
The allocation of the FP
Σ
control unit is fixed.
Control unit I/O No.
FPG-C32T Input: 16 points X0 to XF
FPG-C32T2
Output: 16 points Y0 to YF
FPG-C24R2 Input: 16 points X0 to XF
Output: 8 points Y0 to Y7
I/O No. of expansion unit
I/O numbers do not need to be set as I/O allocation is performed automatically by the
PLC when an expansion I/O unit is added.The I/O allocation of expansion unit is
determined by the installation location.
FPΣ expansion unit
(for left side expansion)
First
expansion
Second
expansion
Third
expansion
Fourth
expansion
FPG-XY64D2T Input: 32 points X100 to X11F X180 to X19F X260 to X27F X340 to X35F
Output: 32 points Y100 to Y11F Y180 to Y19F Y260 to Y27F Y340 to Y35F
FP0 expansion unit
(for right side expansion)
First
expansion
Second
expansion
Third
expansion
FP0-E8X Input: 8 points X20 to X27 X40 to X47 X60 to X67
FP0-E8R Input: 4 points X20 to X23 X40 to X43 X60 to X63
Output: 4 points Y20 to Y23 Y40 to Y43 Y60 to Y63
FP0-E8YT/E8YR/E8YP Output: 8 points Y20 to Y27 Y40 to Y47 Y60 to Y67
FP0-E16X Input: 16 points X20 to X2F X40 to X4F X60 to X6F
FP0-E16R/E16T/E16P Input: 8 points X20 to X27 X40 to X47 X60 to X67
Output: 8 points Y20 to Y27 Y40 to Y47 Y60 to Y67
FP0-E16YT/E16YP Output: 16 points Y20 to Y2F Y40 to Y4F Y60 to Y6F
FP0-E32T/E32P Input: 16 points X20 to X2F X40 to X4F X60 to X6F
Output: 16 points Y20 to Y2F Y40 to Y4F Y60 to Y6F
I/O No. of FP0 analog I/O unit (for right side expansion)
The I/O allocation of FP0 analog I/O unit (FP0-A21) is determined by the installation
location.
Unit First
expansion
Second
expansion
Third
expansion
Input CH0: 16 points WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
CH1: 16 points WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
Output: 16 points WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
