FPΣ
Installation and Wiring
5-16
5.3.3 Precautions Regarding Input and Output Wirings
Be sure to select the thickness (dia.) of the input and output wires while taking into
consideration the required current capacity.
Arrange the wiring so that the input and output wiring are separated, and these wirings
are separated from the power wiring, as much as possible. Do not route them through
the same duct or wrap them up together.
Separate the input/output wires from the power and high voltage wires by at least
100 mm/3.937 in.
To Next Page
