NAiS FP Series User Manual

FPΣ
4.1 I/O Allocation
4-5
4.1.3 I/O Number of FP0 Expansion Unit (for right side expansion)
I/O do not need to be set as I/O allocation is performed automatically when an
expansion unit is added. The I/O allocation of expansion unit is determined by the
installation location.
Type of expansion unit First expansion Second expansion Third expansion
E8X Input (8 points) X20 to X27 X40 to X47 X60 to X67
E8R
Input (4 points) X20 to X23 X40 to X43 X60 to X63
E8R
Output (4 points) Y20 to Y23 Y40 to Y43 Y60 to Y63
E8YR/E8YT/E8YP Output (8 points) Y20 to Y27 Y40 to Y47 Y60 to Y67
E16X Input (16 points) X20 to X2F X40 to X4F X60 to X6F
E16R/E16T/E16P
Input (8 points) X20 to X27 X40 to X47 X60 to X67
E16R/E16T/E16P
Output (8 points) Y20 to Y27 Y40 to Y47 Y60 to Y67
E16YT/E16YP Output (16 points) Y20 to Y2F Y40 to Y4F Y60 to Y6F
E32T/E32P
Input (16 points) X20 to X2F X40 to X4F X60 to X6F
E32T/E32P
Output (16 points) Y20 to Y2F Y40 to Y4F Y60 to Y6F
4.1.4 I/O Number of FP0 Analog I/O Unit (for right side expansion)
The I/O allocation of FP0 analog I/O unit “FP0-A21” is determined by the installation
location.
Unit First expansion Second expansion Third expansion
Input
CH0 (16 points) WX2 (X20 to X2F) WX4 (X40 to X4F) WX6 (X60 to X6F)
I
nput
CH1 (16 points) WX3 (X30 to X3F) WX5 (X50 to X5F) WX7 (X70 to X7F)
Output (16 points) WY2 (Y20 to Y2F) WY4 (Y40 to Y4F) WY6 (Y60 to Y6F)
4.1.5 I/O Number of FP0 A/D Conversion Unit (for right side expansion)
The I/O allocation of FP0 A/D conversion unit “FP0-A80” is determined by the
installation location.
The data for the various channels is converted and loaded with a user program that
includes a switching flag to convert the data.
Unit First expansion Second expansion Third expansion
CH0 (16 points)
CH2 (16 points)
WX2
(X20
to
X2F)
WX4
(X40
to
X4F)
WX6
(X60
to
X6F)
CH4 (16 points)
WX2
(X20
to
X2F)
WX
4
(X
4
0
to
X
4
F)
WX6
(X60
to
X6F)
Input
CH6 (16 points)
I
nput
CH1 (16 points)
CH3 (16 points)
WX3
(X30
to
X3F)
WX5
(X50
to
X5F)
WX7
(X70
to
X7F)
CH5 (16 points)
WX3
(X30
to
X3F)
WX
5
(X
5
0
to
X
5
F)
WX
7
(X
7
0
to
X
7
F)
CH7 (16 points)
