Nikon Eclipse Ti-E User Manual

Chapter 1 Part Names
1.2 Microscope Base
16
1.2.3 Connector Panels
Right connector panel
INTERLOCK
PIEZO
PFS
OFFSET
Figure 1-8 Right connector panel
Rear connector panel
MIC CONTROL
POWER
OFF ON
LAMP CTRL
DC24V IN
USB
Gepruftes Medizinprodukt
Approved medical device
Freiwillige Produktprufung
R
5 3 1 0 0 1
This device complies with Part 15 of the FCC Rules.Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference,and
(2)
EQUIPMENT 4N75
MODEL : Ti-E
INSPECTION
TUV
Rheinland
Product Safety
JAPAN
this device must accept any interference received, including interference
that may cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numØrique de la classe A est conforme  la norme NMB-003 du Canada.
Figure 1-9 Microscope base (rear view)
Epi-fl illumination mount
DC24V IN connector
(for AC adapter)
MIC CONTROL connecto
r
(for Hub Controller A)
PFS connector
(for PFS motorized nosepiece)
OFFSET connecto
r
(for PFS offset controller)
INTERLOCK connecto
r
(for external laser controller)
PIEZO connector
(for PIEZO motorized stage)
USB connector (for PC)
LAMP CTRL connector
(for dia illumination power
supply)
POWER switch
Hub Controller A attachment
screw holes (x4)
Epi-fl illumination attachment
screw holes (x4)
Grooves fo
r
motorized units wiring
(both sides)
