125Service Manual – SC6000 38 - Squeegee System
Specications
Parameter Range
M6 Squeegee Actuator Motor Up: 4.1A initial, then 2.6A
Down: 0.9-1.2A
Special Tools
Actuator Test Kit
The actuator test kit (Pn 56407502) is used to
manually control an actuator removed from the
machine, but powered from a 36-volt battery. It
contains alligator clips to connect to the battery, a
reversing power switch, and a cable connector. If
your test kit is prior to Rev E, you will also need an
adapter cable (Pn 56384816) to connect between the
tester and the SC6000 actuator. This adapter cable is
included in Rev E and above.
