96Service Manual – SC6000 34 - Scrub System, Disc
Removal and Installation
Scrub Deck Doors
The scrub deck doors are removable
for easier access to any of the
components under the machine.
To prevent the doors from coming
off while the machine is in use, the
hinges can’t be separated unless the
doors are open at least half way.
To remove the door, open it about 45
degrees and lift it off the hinges.
Side Squeegees
The side squeegees can be removed
from the scrub deck for maintenance
or easier access to the deck
components.
1. Loosen the rear thumbscrew (A).
2. Slide the squeegee forward, and
then to the side to remove the
assembly.
A
B
B
A
