76Service Manual – SC6000 24 - Electrical System

2 pin connectors

Con Name Pin, Color, ID

X72 Side Sweep Motor

1 = BLU-GRN,W078

2 = ORN-RED,W083

X75 Squeegee Actuator

1 = TAN-BLU,W011

2 = BLK-GRA,W010

X76 Option Pump

1 = WHT-BLK,W225

2 = BLU-ORN,W170

X78 Solution Solenoid

1 = GRY-BLK,W163

2 = GRY,W106

X83 Deck Actuator

1 = BLU-GRA,W014

2 = ORN-GRA,W013

X84 Left Brush Motor

1 = BLU-GRN,W077

2 = BLK-YEL,W082

X128 Right Brush Motor

1 = WHT-VIO,W128

2 = BLU-GRN,W127

X143 Backup Alarm

1 = GRN-BRN,W165

2 = GRY,W108

X145 Vac 2 Motor

1 = ORN-BLU,W085

2 = BLU-GRN,W080

X151 Beacon

1 = BLU-RED,W140

2 = BLK,W145

X168 Side Sweep Sensor

1 = BLK,W135

2 = BLU-BRN,W186
