135Service Manual – SC6000 90 - Options and Accessories
Dust Guard
Requires Main Controller conguration: Yes
Available only when also equipped with the Side
Sweep option. This adds a misting nozzle in front of
the side broom, a solenoid valve on the frame above
the side broom, and a uid pump at the rear of the
machine. The inlet to the uid pump connects to
the moulded solution tube on the scrub deck. Only
one option pump can be installed at a time, so this
option is not compatible with the wash hose option.
Dust Guard is covered in the “34 - Scrub System,
Cylindrical” on page 103.
Beacon
Requires Main Controller conguration: No
The beacon is located on the crossbar behind the operator’s seat. The beacon is active whenever the machine
is powered on. The beacon itself is not covered in the manual, but accessing the wiring connector is shown in
the removal procedure for the “Vacuum Motor” on page 130
Weight Kit
Requires Main Controller conguration: No
The weight kit mounts inside the lower steering column and provides additional weight over the drive wheel
for improved ramp climbing capability. The weight kit is not covered in the service manual.
Foot Guard
Requires Main Controller conguration: No
The foot guard mounts under the foot pedal, and wraps around the pedal to protect the operator’s foot from
overhangin obstructions. The foot guard is not covered in the service manual.
Mop Holder
Requires Main Controller conguration: No
The mop holder is a bracket that mounts to the crossbar or overhead guard. The mop holder is not covered in
the service manual.
Solenoid
Supply
Hose
To Next Page
