 9RLFH $ODUP 6\VWHP Installing an AMG
4-2 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
,QVWDOOLQJDQ$0*
Figure 4-1 contains instructions for installing an AMG module into a CHS-4L chassis:
)LJXUH  ,QVWDOOLQJ DQ $0* 0RGXOH
Step Action
1 Put a standoff on the first
and fourth studs from the
top-left corner of the
CHS-4L chassis.
2 Angle the bottom edge of
the module into the bottom
slot of the CHS-4L.
3 Secure the module to the
CHS-4L with the captive
screws.
&DSWLYH VFUHZ
&DSWLYH VFUHZ
