Preparing for Installation
,QVWDOODWLRQ
AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 2-1
,Q VWDOODWLRQ
3UHSDU LQJ IR U ,Q V WD OODWL RQ
8QSDFNLQJ WKH 6\VWHP
Unpack the system as follows:
%HIRUH LQVWDOOLQJ WKH ILUH DODUP V\VWHP UHDG WKH IROORZLQJ
• Install the system in a readily accessible area with sufficient room to easily install
and maintain the control panel.
• Locate the top of the cabinet approximately 60 inches above the floor with the
hinge mounting on the left.
• Count the number of conductors needed for all devices and find the appropriate
knockouts.
• Review the installation precautions at the front of this manual.
• All wiring must comply with the National and/or Local codes for fire alarm
systems.
• Do not draw wiring into the bottom 9 inches of the cabinet, except when using the
BB-17 or BB-55. This prevents interference between the power supply and
batteries.
6WDQGDUGV DQG &RGHV
In addition, installers should be familiar with the following
standards:
• NEC Article 300 Wiring Methods.
• NEC Article 760 Fire Protective Signaling Systems.
• Applicable Local and State Building Codes.
• Requirements of the Local Authority Having Jurisdiction.
Step Action
1 Carefully unpack the system and inspect for shipping damage.
2 Select a location for the control panel in a clean, dry, vibration-free area with
moderate temperature.
