Notifier AFP-400 Installation Manual

AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 F-1
$SSHQGL[)8/3RZHUOLPLWHG:LULQJ5HTXLUHPHQWV
2YHUYLHZ
Power-limited and nonpower-limited circuit wiring must remain separated in the
cabinet. All power-limited circuit wiring must remain at least 0.25 inches from any
nonpower-limited circuit wiring. All power-limited and nonpower-limited circuit
wiring must enter and exit the cabinet through different knockout and or conduits.
3R ZHUOLPLWHG0RGXOHVDQG&LUFXLWV
1RWH $OO QRQSRZHUOLPLWHG
FLUFXLWV FRQQHFWHG WR $&05
$50 &50 &5( DQG
/'05 PRGXOHV PXVW EH
LGHQWLILHG LQ WKH VSDFH SURYLGHG
RQ WKH FDELQHW GRRU ODEHO
Table F-1 lists all power-limited modules and circuits compatible with the control
panel:
7DEOH ) 3RZHUOLPLWHG &RPSRQHQWV
Power-limited
Components
Include the following...
Modules with power-limited
circuits
ACM-16AT
AEM-16AT
ACM-32A
AEM-32A
AFM-16A
AFM-16AT
AFM-32A
ACT-1
AMG-1
AMG-E
AMG-2
CPU-300
CPU-400
DCM-4
FFT-7
FFT-7S
ICM-4
ICE-4
LCD-80
LCD-80TM
LDM-32
LDM-E32
NIB-96
RPT-485
UDACT
UZC-256
VCE-4
VCM-4
Modules with
nonpower-limited circuits
AA-30
AA-100
AA-120
AVPS-24
MPS-400
4XTM
AC and battery
circuits are
nonpower-limited
Municipal Box circuit
is nonpower-limited
Circuits (dry contacts) on
these modules when
connected to power-limited
sources
ACM-8R
ARM-4
CRM-4
CRE-4
LDM-R32
