Annunciator Selection Groups
A-2 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
$QQXQ FL D WR U6 HOHFWLR Q*URXS V
2YHUYLHZ
The control panel’s annunciation points are divided into nine ACS selection groups of
64 points. Table A-1 contains a list of the ACS Selection Groups, what an annunciator
displays if a group is selected, and where to locate a list of the 64 points within the ACS
Selection Groups.
7DEOH $ $&6 6HOHFWLRQ *URXSV
Notes on ACS Mode for System and Point Annunciation:
When using an LCD-80 in ACS mode for system annunciation, you must assign ACS
Selection Group 1 to the LCD-80’s start address. (For instructions on assigning ACS
Selection Groups, refer to the AFP-300/AFP-400 Programming Manual.) LCD-80s
used in ACS mode for point annunciation can use other ACS Selection Groups for their
start address. Note, however, that annunciators configured for point annunciation:
• Do not respond to any status change, including system alarm or system trouble,
that is not within its ACS Selection Group.
• Do mask status changes for point number 1 of the start address selection.
• Do not respond to System Reset, Acknowledge, or Alarm Silence.
• Do not use the battery saving feature (100 mA battery load).
ACS
Selection
Group
Annunciator Display Refer to...
1 CPU Status and Zones 1-56 Table A-2 on page A-3
2 Zones 57-99, NAC Ckts 1-4 and 16
Special Zones
Table A-3 on page A-4
3 Intelligent Modules 101 to 164 Table A-4 on page A-5
4 Intelligent Modules 201-264 (AFP-400
only)
Table A-5 on page A-6
5 Intelligent Modules 165-196 and
265-296 (AFP-400 only)
Table A-6 on page A-7
6 Detectors 101 to 164 on SLC loop 1 Table A-7 on page A-8
7 Detectors 201-264 on SLC loop 2
(AFP-400 only)
Table A-8 on page A-9
8 Detectors 165-196 and 265-296
(AFP-400 only)
Table A-9 on page A-10
9 NAC/Panel Output Circuit Modules
(64 points)
Table A-10 on page A-11
* or 0 Annunciator Not Installed At Address N/A
