Notifier AFP-400 Installation Manual

 ,QVWDOODWLRQ Installing a Cabinet Door
2-4 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
,QVWDOOLQJD&DELQHW'RRU
&DELQHW'RRU0RXQWLQ
J
*XLG H OLQHV
Cabinet doors mount in a left- or right-hand opening configuration, providing easier
access for installation and service when two control panels are mounted in a confined
area or side-by-side (as shown in Figure 2-1). The doors can be opened barn door style,
creating an open work space. Before mounting any equipment in the backbox, make
sure to attach the two hinges and the two alignment tabs. In this type of installation it is
necessary to leave enough space between cabinets to insert a key into the locks on the
door frames.
)LJXUH  &DELQHW 'RRU 0RXQWLQJ 3RVLWLRQV
+RZWR,QVWDOOD&DELQHW'RRU&$%;RQO
\

1RWH 3ODFLQJ WKH GRRU RQ WKH
ORZHU VWXG ILUVW SURYLGHV D SODFH
IRU WKH GRRU WR UHVW ZKLOH
FRPSOHWLQJ WKH DVVHPEO\
You can mount hinges on the left or right. The drawings and text refer to a left-mounted
example. For right hand mounting, substitute right for left in the instructions. Follow
the instructions in the installation table and refer to the drawings.
Table 2-3 Cabinet Door Installation Instructions
,QVWDOOLQJ D 7RS +LQJH
Figure 2-2 shows how to mount a top hinge on a door:
)LJXUH  ,QVWDOOLQJ D 7RS +LQJH
/HIWKDQG PRXQWHG GRRU
5LJKWKDQG PRXQWHG GRRU
Step Action
1 Insert the door hinges (A) into the top and bottom slots.
(Figure 2-2 and Figure 2-3).
2 Attach the mounting nuts and secure the hinges to the backbox studs so the small
hole on the outer tab faces out.
3 Thread the stud (B), from the bottom up, into the bottom hinge first. Place the
grounding star washer and the lower corner of the door onto the stud.
4 Align the door on the backbox so the door sits directly under the top hinge. Thread
the remaining stud (B) into the top hinge and through the hole in the top of the
door. The door should now swing freely.
+LQJH $
7RS /H IW & RUQHU
6WXG %
1RWH 7KH LQVWDOODWLRQ LV
WKH VDPH IRU WKH WRS DQG
WKH ERWWRP ULJKW FRUQHU RI
WKH EDFNER[
