$SSHQGL[ ( 7HUPLQDO ,QWHUIDFH 3URWRFRO
Using the CRT-2 for Read Status
E-4 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
8VLQJWKH&57IRU5HDG6WDWXV
2YHUYLHZ
This section shows how to do Read Status functions from a CRT-2.
7DEOH ( 5HDG 6WDWXV )XQFWLRQV
$FFHVVLQ
5HDG6WDWXV2
WLRQV
Access the Read Status function from the CRT-2 by following these steps.
1. Turn on the CRT-2, which is connected to the control panel.
2. Press the Read Status function key – F1. The control panel displays the Read Status
menu options:
From the Read Status menu, you can select options 1-5.
Function Lets you...
Read Point Read the status of any point in the system (detectors, modules, panel circuits,
software zones, and system parameters).
Alm/Tbl Status Display a list of all devices in the system that are in Alarm or trouble.
Read All Points Display a list of all points programmed in the system. This list will display the
status of all addressable detectors, modules, panel circuits, system parameters and
software zones.
History Step Step through the history buffer one event at a time.
History-All Send the entire history buffer to the CRT, from the most recent event to the oldest
event.
5G 3RLQW 5G $OP7EO $OO 3RLQWV +LVW6WHS $OO $OD+LVW6WHS $O
!
