NOVA chat User’s Guide Page 29
Replacing the Wheelchair Mounting Plate: NOVA chat 12
Your NOVA chat 12 device shipped with the wheelchair mounting plate
installed. If you need to replace it, follow these instructions.
1. Place the device face-down on a flat surface. Be careful not to
scratch the display.
2. Remove the three screws from the old mounting plate and remove
the plate from the back of the device.
3. Align the three tapered holes in the new mounting plate with the
three threaded holes on the back of the device.
Important! Be sure that the plate is oriented so that the additional
hole for the holding pin is in the upper left.
4. Insert and tighten the screws.
Store or dispose of the old mounting plate and screws safely. Loose
screws can be a choking hazard.
